Elicent AXC 150 TP – Centrifugal Inline Fan 150mm Duct with Mounting Brackets – Plastic

Name: Elicent AXC 150 TP - Centrifugal Inline Fan 150mm Duct with Mounting Brackets - Plastic
Brand: Elicent
SKU: W-EXELAXCP150-BR
Availability: InStock

$249.00

RRP $289.00

$40.00 OFF

Italian-made high-performing centrifugal inline fan
Specifically designed for 150mm ducted ventilation systems
Versatile enough for residential & limited commercial applications
Impressive airflow capacity of 430 m3/hr

SKU: W-EXELAXCP150-BR

Product Details

Elicent AXC 150 TP Features Overview:

Capacity	430 m3/hr (119.44 l/s)
Noise	39 dB(A)
Motor RPM	2560
Ductable	Yes – 150mm diameter

Its high-performance centrifugal design enables substantial pressure generation for adequate air movement in complex ducted systems.
The compact Inline design simplifies integration into ventilation systems, ideal for space-limited installations.
Durable Plastic/Technopolymer Construction provides a lightweight, corrosion-resistant, non-flammable, and self-extinguishing housing for longevity and safety.
The reliable ball-bearing motor ensures maintenance-free continuous operation and an extended lifespan.
The thermal cut-out enhances safety by preventing motor overheating.
Minimises noise disruption and is suitable for noise-sensitive environments.
IP Rating – IPX2.
This fan requires hardwiring by an electrician.
Mounting Brackets: Included for secure installation.
Versatile Mounting Options: Allows installation in various positions to accommodate different ductwork layouts.

View the comprehensive manuals below to learn more about the product and how it’s installed.

Refer to this spec sheet for more information: AXC-TP- Spec Sheet.

Refer to this user manual for more information: AXC TP User Manual.

Refer to this wiring manual for more information: Wiring Diagrams – AXC TP.

Key Specs

Brand	Elicent
Colour	White
Installation	Requires Hardwiring (electrician required)
Warranty	Elicent: The manufacturer offers a 2 year replacement warranty (conditions apply).
Motor Type	Centrifugal
Manufacturers Part Number	2AX6100
Barcode Number	8016510000838

All data is provided the manufacturer. Capacity figures are based on the extraction rate of the unit in ‘freeflow’. This means without any ducting, vents or other components. As you add ducting to a fan it will impact the extraction rate as this introduces resistance. For this reason if you are ducting an extraction fan it is best to keen the run as short, tight and direct as possible. For more information please view our exhaust fan buying guide.

For comprehensive warranty information relating to this product please visit the manufacturers website.
