Elicent AXC 125 TP – Centrifugal Inline Fan 125mm Duct – Plastic
Original price was: $259.00.$219.00Current price is: $219.00.
- Sleek design with reliable high-performance centrifugal inline fan
- Tailored for 125mm ducted ventilation systems
- Constructed from robust plastic or a high-performance technopolymer
- Suitable for residential and limited commercial use
- With an impressive airflow capacity of around 265 m3/hr
- Efficient ventilation with a noise level of 33 dB(A)
- Made in Italy
Compatible Accessories
-
Linear Slot Vent Metal White 900mm
Original price was: $209.00.$189.00Current price is: $189.00. -
-
Roof Cowl Kit Tiled Roof – 125mm
Original price was: $159.00.$139.00Current price is: $139.00. -
- Description
- Additional information
- Reviews (0)
Description
Elicent AXC 125 TP Features Overview:
| Capacity | 265 m3/hr (73.61 l/s) |
|---|---|
| Noise | 33 dB(A) |
| Motor RPM | 2400 |
| Ductable | Yes – 125mm diameter |
Its high-performance centrifugal design enables substantial pressure generation for adequate air movement in complex ducted systems.
The compact Inline design simplifies integration into ventilation systems, which is ideal for space-limited installations.
Durable Plastic/Technopolymer Construction provides a lightweight, corrosion-resistant, non-flammable, and self-extinguishing housing for longevity and safety.
The reliable ball-bearing motor ensures maintenance-free continuous operation and an extended lifespan.
The thermal cut-out enhances safety by preventing motor overheating.
Minimizes noise disruption and is suitable for noise-sensitive environments.
IP Rating – IPX2.
This fan requires hardwiring by an electrician.
Plastic Mounting Bracket: Included for secure installation.
Versatile Mounting Options: Allows installation in various positions to accommodate different ductwork layouts.
View the comprehensive manuals below to learn more about the product and how it’s installed.
Refer to this spec sheet for more information: AXC-TP- Spec Sheet.
Refer to this user manual for more information: AXC TP User Manual.
Refer to this wiring manual for more information: Wiring Diagrams – AXC TP.
Additional information
| Brand | Elicent |
|---|---|
| Colour | White |
| Installation | Requires Hardwiring (electrician required) |
| Warranty | Elicent: The manufacturer offers a 2 year replacement warranty (conditions apply). |
| Motor Type | Centrifugal |
| Manufacturers Part Number | 2AX5151 |
BarCode Number : 8016510000821
All data is provided the manufacturer. Capacity figures are based on the extraction rate of the unit in 'freeflow'. This means without any ducting, vents or other components. As you add ducting to a fan it will impact the extraction rate as this introduces resistance. For this reason if you are ducting an extraction fan it is best to keen the run as short, tight and direct as possible. For more information please view our exhaust fan buying guide.
For comprehensive warranty information relating to this product please visit the manufacturers website.
