Fanco Sanctuary Key Features
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | Solid Timber |
| Overall Diameter | 218cm (86″) |
| Blade Pitch | 10 Degrees |
| Motor Type | DC |
| Control Type | Remote Control |
| Summer / Winter use? | Reversible from remote |
| Ceiling to Blade Drop | 447mm (517mm to base of light) |
| Angled Ceilings? | Suitable for angled ceilings up to 15 degrees |
| Light Included? | Included |
The Fanco Sanctuary features anti-corrosive paint on all metal components and solid timber blades coated with a protective sealer, offering a stylish finish ideal for alfresco, outdoor, and coastal settings.
Fanco Sanctuary Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 78 | 12 | 3,460 m3/hr |
| 2 | 87 | 15.6 | 6,569 m3/hr |
| 3 | 98 | 22.2 | 9,089 m3/hr |
| 4 | 110 | 30 | 11,246 m3/hr |
| 5 | 121 | 39.8 | 12,005 m3/hr |
| 6 | 131 | 54.3 | 14,052 m3/hr |
The fan can be used all year due to its reversible motor controllable with the remote, such that warm air is circulated throughout the room during cooler months, and a high airflow cooling is still functional in the summer.
Understanding the Fanco Sanctuary Light
| Light Type | LED |
|---|---|
| Light Wattage | 24W |
| Lumens | 1435lm, 1474lm or 1461lm |
| Light Temperature | 3000K, 4000K or 6000K |
| Dimmable | Yes |
CCT stands for colour changing technology which means you can select a desired temperature depending on your preferences.
Change the light temperature by pressing the light on/off button on the remote quickly, or by using the smart app. Select from warm white, natural or daylight light temperatures. The light has memory capability that keeps the settings when the light is switched off. The LED panel is user replaceable, this means that you can purchase a replacement / spare panel and swap it over yourself if required.
For detailed measurements, technical configurations, and step-by-step setup guides, please download the product spec sheet, installation manual and smart ceiling fan set up guide here.
CLICK TO DOWNLOAD FANCO SANCTUARY SPEC SHEET
CLICK TO DOWNLOAD FANCO SANCTUARY INSTALLATION MANUAL
Please note: As solid timber blades are made from natural materials, slight variations in performance specifications may occur. Due to its larger size and extended 447mm ceiling-to-blade drop, the Sanctuary is recommended for ceilings with a minimum height of 2.7m. A qualified person must carry out installation of the fan and all components. For outdoor installations, the fan must be positioned at least 1.5m from the roof edge or eaves and maintain a minimum 70cm clearance between the blade tips and any walls, roof edges, or ceiling beams.
