Fanco Sanctuary Key Features
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | Solid Timber |
| Overall Diameter | 132cm (52″) |
| Blade Pitch | 12 Degrees |
| Motor Type | DC |
| Control Type | Remote Control |
| Summer / Winter use? | Reversible from remote |
| Ceiling to Blade Drop | 277mm (330mm to base of light) |
| Angled Ceilings? | Suitable for angled ceilings up to 15 degrees |
| Light Included? | Included |
The Fanco Sanctuary features anti-corrosive metal components and solid timber blades coated with a protective sealer, ensuring durability and style in outdoor and coastal settings. It also includes a convenient timer with options of 1H, 4H, or 8H.
Fanco Sanctuary Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 61 | 1.7 | 3,556 m3/hr |
| 2 | 86 | 3.3 | 4,499 m3/hr |
| 3 | 112 | 6.2 | 5,939 m3/hr |
| 4 | 137 | 11.2 | 6,809 m3/hr |
| 5 | 162 | 19.3 | 7,878 m3/hr |
| 6 | 182 | 29.2 | 9,037 m3/hr |
Can be used year-round, with reversible airflow via the included remote. Low running costs; uses only 29.2W from an efficient DC motor at max speed, where airflow is produced at 9,037 m3/hr.
Understanding the Fanco Sanctuary Light
| Light Type | LED |
|---|---|
| Light Wattage | 20W |
| Lumens | 2102lm, 1959lm or 1956lm |
| Light Temperature | 3000K, 4000K or 6000K |
| Dimmable | Yes |
CCT stands for colour changing technology, which means you can select a desired temperature depending on your preferences.
The LED panel is user-replaceable; this means that you can purchase a replacement / spare panel and swap it over yourself if required.
For detailed measurements, technical configurations, and step-by-step setup guides, please download the product spec sheet, installation manual and smart ceiling fan set up guide here.
CLICK TO DOWNLOAD FANCO SANCTUARY SPEC SHEET
CLICK TO DOWNLOAD FANCO SANCTUARY INSTALLATION MANUAL
Please note: Solid timber blades are made from natural materials and may vary slightly in performance specifications. It includes both a 127mm and a 254mm extension rod, allowing you to choose the most suitable drop for your ceiling height and room layout. A qualified person must complete installation. When installed outdoors, the fan must be positioned at least 1.5m from roof edges or eaves, with a minimum 70cm clearance between the blade tips and surrounding walls, roof edges, or ceiling beams.
Duncan (verified owner) –
Great style and good air movement from a fan that can be located indoors and outdoor which is critical for my location on an island in north Queensland
